Datacom DM4000 Series User Manual

Chapter 3. Technical Specifications
Figure 3-2. DM4004 Power Supplies Connectors
3.2.3. DM4008
Table 3-5. Recommended Power Limits and Consumption Parameters for DM4008
Rec. Voltage Limits Power Type Power max. Current max.
min. max.
-48V -60V DC 1200W 25.00A
Table 3-6. Absolute Power Limits for DM4008
Absolute Voltage Limits Power Type Power max. Current max.
min. max.
-36V -72V DC 1200W 33.33A
Figure 3-3. DM4008 Power Supplies Connectors
3.2.4. Interface Modules
Table 3-7. Consumption and Fuse
Interface Module Fuse Consumption
ETH24GX 3.15A fuse, type T (delay), 250V 90W
ETH24GX H Series 3.15A fuse, type T (delay), 250V 70W
ETH12GX 3.15A fuse, type T (delay), 250V 45W
ETH12GX+1x10GX 3.15A fuse, type T (delay), 250V 80W
ETH24GX+2x10GX H Series 3.15A fuse, type T (delay), 250V 80W
9
