Chapter 3. Technical Specifications
Table 3-2. Absolute Power Limits for DM4001
Absolute Voltage Limits Power Type Power max. Current max.
min. max.
-36V -72V DC 200W 4.7A
Follow Power information below screws to correct RET / -48V connections
Figure 3-1. DM4001 Power Supplies Connectors
3.2.2. DM4004
Table 3-3. Recommended Power Limits and Consumption Parameters for DM4004
Rec. Voltage Limits Power Type Power max. Current max.
min. max.
-48V -60V DC 576W 12.00A
Table 3-4. Absolute Power Limits for DM4004
Absolute Voltage Limits Power Type Power max. Current max.
min. max.
-36V -72V DC 576W 16.00A
8
