Datacom DM4000 Series User Manual

Chapter 10. DM4000 ETH24GX
10.3. System Status LEDs
The DM4000 ETH24GX has the following port status LEDs.
Figure 10-3. DM4000 ETH24GX - Front Panel LEDs
Table 10-1. ETH24GX Port Status LEDs
LED CONDITION STATUS
Link/Act ON/Blinking Connection established. Blinking indicates port
activity.
OFF No connection established.
10/100/1000 Orange Indicates that a 10/100Mbps connection was
established.
Green Indicates that a 1000Mbps connection was
established.
10.4. Software and Hardware Features
10.4.1. Software
Software information is available in a separated guide.
