Chapter 3. Technical Specifications
3.1. Environmental Conditions
Operating Temperature: 0 to 55 degrees Celsius
Storage Temperature: -20 to 65 degrees Celsius
Humidity: 10 to 90% non condensing
3.2. Power Supply
The DM4000 family has a DC power input range of -48 to -60 V
WARNING:
"Before connecting any cable to the equipment, be sure that the grounding system is functional."
WARNING:
"The power supply, where the supply cable is connected, must be positioned near the equipment and have
easy access, because the equipment is turned on and off through it."
3.2.1. DM4001
Table 3-1. Recommended Power Limits and Consumption Parameters for DM4001
Rec. Voltage Limits Power Type Power max. Current max.
min. max.
-48V -60V DC 200W 3.5A
7
