Chapter 15. DM4000 ETH24GT

15.4.2. Hardware

Table 15-2. Hardware DM4000 ETH24GT

Feature Description

Switch L2 Wire Speed

Router 3 Wire Speed

QoS L2-L4

MPLS N/A

PoE N/A

Ports 24 x 10/100/1000 Base-TX

Packet Buffer 2MB

Switch Fabric (intern) 48Gbps

Flash 64MB

SDRAM 256MB

MAC address table 16k

L3 hosts (IPv4) 8k

L3 hosts (IPv6) 4k

L3 Routes (IPv4) 12k

L3 Routes (IPv6) 6k

L2 Multicast groups 1k

L3 Multicast groups (Ipv4) 2k

L3 Multicast groups (IPv6) 512

Filters 4k

Meters 2k

Counters 2k

For operation with PoE: the voltage of power supply must be between 44-57V.
