BARCODE CONFIGURATION
PRODUCT REFERENCE GUIDE
121
•See “Logical Combination” on page 127: Logical Combination allows for grouping bar
codes together. You can create an AND or Xor condition. For example: if three codes are
enabled each bar code can be put into separate groups creating an AND condition or you can
place two of the bar codes in one group and a third bar code in a separate group. Group 1
(code 1 or code 2) Group 2 (code 3). You can have either code 1 OR code 2 read and it's data
will be place in Group's 1 field. In Logical Combination mode the codes of the groups defined
by the Logical Combination Rule are read in the same reading phase.
•
See “Code Collection” on page 135: In Code Collection mode expected codes are
collected within a single reading phase in the order in which they are read. The No Read
message is produced only if none of the codes are read. Up to 50 codes can be collected.
Based on your code combination selection, different fields will become available. See
the following sections for the details of your code combination.
3. When you have finished making changes, click Update to save or click Reset to
r
evert
to the previously saved values.
In case of Standard Multi Label, the codes will be distinguished EITHER by their symbol-
ogy, OR by their contents. If two (or more) codes share the same symbology and con-
tent, the barcode reader will perceive them as a unique code.
