CBX510 CONNECTION BOX
PRODUCT REFERENCE GUIDE
55
Photoelectric Sensor Connections to CBX510
Barcode scanning applications may use a Datalogic photoelectric sensor as a trigger
device. The photoelectric sensor is wired directly into the CBX510 terminal block.
If your application uses a trigger other than the one specified b
y Datalogic, follow the
appropriate wiring diagram to assure proper wiring.
The following diagrams illustrate standard recommended wiring of the Photoelectric
Sensor to the CBX510 terminal block.
To confirm the photoelectric sensor is functioning prope
rly, watch the TRIGGER
LED first in
the CBX and then on the camera while the photoelectric sensor’s beam is blocked. The Data-
logic photoelectric sensor also includes a status LED.
