Datalogic AV900 - Unpowered Outputs

TRIGGER AND FOCUSING DEVICE WIRING
PRODUCT REFERENCE GUIDE 75
Outputs 1 and 2
Maximum Voltage 30V
Collector Current (pulse) 130 mA Max.
Collector Current (continuous) 40 mA Max.
Saturation Voltage (VCE) 1 V at 10 mA Max.
Max Power Dissipation 90 mW at 50 degrees C
(Ambient temperatur
e)
Unpowered Outputs
