E-GENIUS
146
AV500/AV900 2D CAMERA
Enable
Select one of the following from the drop-down.
•Disable: The selected communication channel is not used for Protocol Index string
communication.
•Without Request Message: An external device, such as a host index number, will send a
message to the camera.
•With Request Message
: An external device, such as a host index number, sends a message
to the camera, when the trigger detects the presence of a pack, before transmitting the
Protocol Index string associated to the pack itself on the selected communication channel.
Header
Click to activate the “The Text Entry Tool” on page 81 and create a Header (up to 128
bytes) to be defined and transmitted as a block preceding the Protocol Index string sent by the
Host. Use characters from NUL (00H) to ~ (7EH).
Click Submit to save your changes, or click Cancel to return to the previous window.
Terminator
Click to activate the “The Text Entry Tool” on page 81 and create a Terminator to be
defined and transmitted as a block following the Protocol Index string sent by the Host. Use
characters from NUL (00H) to ~ (7EH).
Click Submit to save your changes, or click Cancel to return to the previous window.
Length Type
Select Variable Length, Length in Message, or Fixed Length from the drop-down list.
•Variable Length: The length of the Protocol Index string sent by the Host is variable.
•Length in Message: The first byte of the output message indicates the length of the Protocol
Index string sent by the Host.
•Fixed Length: The Protocol Index string has a fixed length from 3 to 12 characters.
No Index String
Click to activate the “The Text Entry Tool” on page 81 and create a No Index String. Click
Submit to save your changes, or click Cancel to return to the previous window.
This parameter defines the string to be transmitted instead of the Protocol Index within the
output message when no Protocol Index string has been associated to the package.
Request Message
The Request Message is the message that the camera sends to the external component,
requesting the component to send the protocol message. Only available when “With Request
Message is enabled.”
Delay Request Message
When unchecked, the request message gets sent at start of trigger. Select this check box and
the request message will be delayed by the Reference Edge and Distance to Trigger Line
specified here.
Message Placing Wizard
See “Diagnostics | Message Placing Wizard” on page 254
Reference Edge
Select Leading or Trailing from the drop-down list. This is the edge of the package when the
external component will send the message.
Distance to Trigger Line
Enter the distance from the trigger line to the point where the camera will receive the protocol
index message.
This parameter specifies the distance from the physical Trigger Line (i.e. Trigger Source) to the
expected receiving point of the Protocol Index, measured in mm or inches. It is used together
with the Minimum Distance Between Two Consecutive Objects (below) parameter to assign
The Header and Terminator need to match the external component.
