IMAGE SAVING
PRODUCT REFERENCE GUIDE
167
Image Name Item n
Item Type
Select an Image Name item type from the drop-down list, including:
•
Parcel ID: Uses the parcel ID as the Image Name
•
Image Specific String: Uses the image string entered above
•
Date: Uses the current date (yyyymmdd)
•
Time: Uses the image scan time (hhmmss)
•
Analysis Result: Adds read analysis code to the image naming convention
•
Protocol Index: Uses the protocol index data, as defined in the following options. the
Protocol Index allows for the selection of the transport (communication port) that the
Protocol Index is received on.
•
String this is a free form box allowing for text characters to be entered.
•
Camera Specific String the Camera Specific String is the name applied to the camera in
the above Image Name>Specific String field
•Code
•Counter
•Frame ID
•Frame Index
If String is selected
IString uses the character string entered below
Item String (Max 16 Chars.)
Select a transport number from the drop-down list
Camera Specific String appends the specified string to the image file name.
If Code is selected
Code Group Index
Logical combination group number as specified in Barcode Settings | Barcode configuration
Cutting Mode
Select Disabled or Simple from the drop-down list. When Simple is selected from the options
below are revealed.
Number of Leading Characters to Cut
Enter a number indicating the number of characters to cut from the leading part of the
message.
Number of Trailing Characters to Cut
Enter a number indicating the number of characters to cut from the trailing part of the
message.
If Counter is selected
Counter: Uses a counter as described below
Counter Module
Enter the number maximum for the counter before it turns over to start at 1 again.
Alignment
Select None, Left, or Right from the drop-down list. When Left or Right is selected the
options below are revealed.
Align Length
Enter the number of characters to fill with the Align Filler Character.
Align Length is the number of characters to fill if the counter value if less than the maximum
number. Its main purpose is to make the field length consistent no matter what the counter
value.
You must select Frame ID or Index if you are sending images to a WebSentinel PLUS
Server. This creates unique filenames for each frame, which is necessary for capturing
frames and saving them with WebSentinel PLUS.
