E-GENIUS
220
AV500/AV900 2D CAMERA
Spacing: the space between the current and previous package. This is posted in millimeters
and inches. When the camera is mounted to read multiple surfaces of the package (ie side and
back) this parameter specifies a condition where one package, because of illegal spacing,
blocks part of the surface of another package. The camera is able to detect this condition and
will post pertinent information.
Volumetric: The Volumetric information is valid when the camera is connected to a DM3610.
The camera will take the data it receives for the package from the DM3610 and fill the
appropriate fields general package size/position
Shadowing: Indicates camera spacing and whether there is shadowing
DM3610 Msg Tracking: When the DM3610 transmit message is set to Camera Message, the
camera will receive the data without the need for any other configuration such as Protocol
Index. When this is set and the message is not received within the correct package tach stamp,
it will post the Msg Missed Window in this field.
Protocol Index: Protocol data if enabled. Identifies when the Protocol Index window opens
and closes and the position of the parcel in tach/encoder pulses.
Transmit Messages: The Transmit Message field will identify the enabled communication
Transport and the message that is transmitted out of that port.
Image Saving: Stored Images are displayed for each camera. Click on the link to access a view
of that camera’s images. Camera N’s Images. see “Viewing Camera Images” on page 227, view
of the cameras image for the select sequence number.
Decoding Status: Identifies the decoding status of each camera in the array and the
processing load (how hard the processor has to work to decode the bar code). The higher the
number the more processing time it took to identify the bar code data.
Image Analysis:
Decode Results:
Posts the barcode data and indicates the camera that read the code
End of Sequence Number: Identifies the total number of packages with history stored in the
camera
Camera Statistics
Statistics for each system camera are shown in rows with the following columns:
Camera Name
Displays the camera/device name. Click the device name to view details about that specific
device:
