DIAGNOSTICS | IMAGE VIEWER
PRODUCT REFERENCE GUIDE
235
5. Each package is labeled with its sequence number and read status:
Barcodes In means a decode is placed on a package.
Barcodes Out means a decode
is not placed on any package.
Barcodes Uncertain means it
is uncertain which package the decode belongs to (e.g.
two packages are too close).
6. Select a do
wn samp
ling number from the drop-down list. Choose a lower number
to see a fuller resolution of the image. Choose a higher number to view an image
during operation.
7. Click Stop to cease capturing images.
8. Click Fit to Scr
een to zoom the image to fill the view window.
9. Controls:
•Click an image multiple times to zoom in.
•Hold <
SHIFT> and click an image multiple times to zoom out.
•Roll the mouse wheel to zoom in or out.
•Click, hold and slide to pan an image.
Contact Datalogic Tech Support before making any calibration adjustments.
The White Level field displays the image white level based on where the cursor is posi-
tioned. The X,Y values field displays the cursor coordinates.
Do not use down-sampling numbers lower than 16 when viewing images during live
sort. It will increase the processing time of the camera and could cause no reads.
