INSTALLATION – DS8100 SERIAL INTERFACE
15
2
Output Signal Connector
5
1
69
Figure 12 - Output Signal connector
Output Signal Connector pinout
Pin Name Function
1 VS supply voltage (positive pin)
2 GND supply voltage (negative pin)
3 NO READ+ no read output (positive pin)
4 NO READ- no read output (negative pin)
5 RIGHT+ right code output (positive pin)
6 RIGHT- right code output (negative pin)
7 SPS+ slave presence sensor (positive pin)
8 SPS- slave presence sensor (negative pin)
9
Main Interface Connector
5
1
69
Figure 13 - Main Interface connector
Main Interface Connector pinout
Pin RS232 RS485
full-duplex
RS485
half-duplex
20 mA C.L.
1 DRVREF
2 TXD TX485+ RTX485+ CLOUT+
3 RXD TX485- RTX485- CLOUT-
4 DRVIN
5 GND GNDRS485 GNDRS485
6 RS485CNTR
7 CTS RX485+ CLIN+
8 RTS RX485- CLIN-
9 DRVOUT
* The function of these pins depends on the interface type selected.
