Datalogic Magellan 1100i Product Reference Guide

176 Magellan
TM
1100i
Physical Properties
Electrical Parameters
Environmental Parameters
Other Parameters
Parameter Specification
Dimensions (Scanner only): 3.3” x2.8” x3.7”
Dimensions (Scanner w/Base
Station):
5.5” x2.9” x3.8”
Weight (Scanner) 7.0 oz.
Weight (Base Station) 6.6 oz.
Parameter Specification
Operating Voltage Input voltage 4.5 to 14 VDC
Input Current
Operating (idle)
Operating (label read)
<300mA
<400 mA
Parameter Specification
Mechanical Shock Multi 1.2m drops
Contaminants
Water and Dust IP52
Temperature Ranges:
Operating 32 F to +104 F (0 C to +40 C)
Storage -40 F to +158 F (-40 C to + 70C)
Ambient Light Indoor 0 - 6000 lux
Ambient Light Outdoor 0 - 86,100 lux
Humidity 5 to 95% non-condensing
Beeper/Speaker 70-85dBA at a distance of 3’-3” (1 meter)
Vibration Retail/Office
Parameter Specification
EAS Support YES (Checkpoint)

Datalogic Magellan 1100i Specifications

General

Yaw reading angle	-75 - 75 °
Decoding standards	-1D + GS1 DataBar, -GS1 DataBar Composites, -GS1 DataBar Expanded Stacked, -GS1 DataBar Stacked, -GS1 DataBar Stacked Omnidirectional, -MicroPDF417, -PDF417.
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Standard interfaces	USB, RS-232
Input voltage	4.5 - 14 V
Power consumption	400 mA
Dimensions (WxDxH)	84 x 71 x 94 mm
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	198.5 g
