Interface Related Features
50
Magellan
TM
1100i
RS-232 Interface Features — cont.
ACK NAK Retry Count
START / END
PROGRAMMING BARCODES
This feature sets the number of times for the scanner to retry a label transmission under a retry condition.
000 = No retry
001 - 254 = Retry for the specified number of times
255 = Retry forever
To configure this feature, scan the “START/END” barcode above to place the unit in Programming Mode, then the “Set ACK NAK
Retry Count,” followed by the three digits (zero padded) from the Alphanumeric table in
Appendix C, Alpha-Numeric Pad repre-
senting your desired retry count. Exit programming mode by again scanning the “START/END” barcode above
DEFAULT SETTING FOR THIS FEATURE: 003
Set ACK NAK Timeout Value
