Datalogic Magellan 1100i Product Reference Guide

Product Reference Guide 31
Chapter 3
Interface Related Features
At the time of this writing, the reader supports the interfaces listed in Tabl e 3- 1 . Select the
desired interface type from the table, then reference the page number given for the customizable
features section associated with each interface. See
Ta bl e 3 -2 for a description of each Keyboard
Wedge interface type (A through Y as listed).
Table 3-1. Interfaces Supported
RS-232 Page Keyboard Wedge 3-34
RS-232 Standard
3-33
Keyboard Wedge A
a
a. Consult Table 3 -2 for more information regarding keyboard interface
types.
3-34
RS-232 Wincor-Nixdorf
3-33
Keyboard Wedge B
a
3-34
IBM
Keyboard Wedge C
a
3-34
IBM 4683 Port 5B
3-33
Keyboard Wedge D
a
3-34
IBM 4683 Port 9B
3-33
Keyboard Wedge E
a
3-34
IBM 4683 Port 17
3-33
Keyboard Wedge F
a
3-34
USB
Keyboard Wedge G
a
3-34
USB-OEM
3-33
Keyboard Wedge H
a
3-34
USB Keyboard
3-33
Keyboard Wedge I
a
3-34
USB COM Interface
3-33
Keyboard Wedge J
a
3-34
NOTE
The correct interface cable is included for the reader
interface type you ordered.

Datalogic Magellan 1100i Specifications

General

Yaw reading angle	-75 - 75 °
Decoding standards	-1D + GS1 DataBar, -GS1 DataBar Composites, -GS1 DataBar Expanded Stacked, -GS1 DataBar Stacked, -GS1 DataBar Stacked Omnidirectional, -MicroPDF417, -PDF417.
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Standard interfaces	USB, RS-232
Input voltage	4.5 - 14 V
Power consumption	400 mA
Dimensions (WxDxH)	84 x 71 x 94 mm
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	198.5 g
