Datalogic Magellan 1100i Product Reference Guide

Interface Default Exceptions
Product Reference Guide 183
Interface Default Exceptions — continued
RS-232 Wincor/Nixdorf
Parameter Default Setting
Interface Type RS-232-WN
Number of Host Transmit Buffers One Buffer
RS-232 Parity Odd
RS-232 Hardware Control CTS Flow Control
UPC-E Check Character Conversion Disabled
UCC/EAN-128 Label ID ‘P’
Code 39 Label ID ‘M’
Code 93 Label ID ‘L’
Code 128 Label ID ‘K’
Codabar Label ID ‘N’
EAN-8 Label ID ‘B’
EAN-13 Label ID ‘A’
ISBN Label ID ‘A’
Interleaved 2 of 5 Label ID ‘I’
Standard 2 of 5 Label ID ‘H’
MSI/Plessey Label ID ‘O’
UPC-E Label ID ‘C’
GS1 DataBar Omnidirectional Label ID ‘E’
GS1 Expanded Label ID ‘E’

Datalogic Magellan 1100i Specifications

General

Yaw reading angle	-75 - 75 °
Decoding standards	-1D + GS1 DataBar, -GS1 DataBar Composites, -GS1 DataBar Expanded Stacked, -GS1 DataBar Stacked, -GS1 DataBar Stacked Omnidirectional, -MicroPDF417, -PDF417.
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Standard interfaces	USB, RS-232
Input voltage	4.5 - 14 V
Power consumption	400 mA
Dimensions (WxDxH)	84 x 71 x 94 mm
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	198.5 g
