Datalogic Magellan 1100i Product Reference Guide

190 Magellan
TM
1100i
Table E-7. Japanese DOS Function Key Map
ASCII value ASCII code Key Scancode
00h NUL ALT right Make 31h
01h SOH ALT right Break B1h
02h STX ALT left Make 31h
03h ETX ALT left Break B1h
04h EOT CTRL left Make 41h
05h ENQ CTRL left Break C1h
06h ACK CTRL right Make 41h
07h BEL CTRL right Break C1h
08h BS BS 3Eh
09h HT TAB right 3Ch
0Ah LF RIGHT arrow (inner keypad) 4Dh
0Bh VT TAB left 3Ch + S
0Ch FF Enter (right keypad) 60h
0Dh CR CR 3Bh
0Eh SO INSERT (inner keypad) 52h
0Fh SI PAGE UP (inner keypad) 49h
10h DLE PAGE DOWN (inner keypad) 51h
11h DC1 HOME (inner keypad) 4Ch
12h DC2 LEFT arrow (inner keypad) 4Bh
13h DC3 DOWN arrow (inner keypad) 4Ah
14h DC4 UP arrow (inner keypad) 4Eh
15h NAK F6 6Dh
16h SYN F1 68h
17h ETB F2 69h
18h CAN F3 6Ah
19h EM F4 6Bh
1Ah SUB F5 6Ch
1Bh ESC ESC 3Dh
1Ch FS F7 6Eh
1Dh GS F8 6Fh
1Eh RS F9 70h
1Fh US F10 71h

Datalogic Magellan 1100i Specifications

General

Yaw reading angle	-75 - 75 °
Decoding standards	-1D + GS1 DataBar, -GS1 DataBar Composites, -GS1 DataBar Expanded Stacked, -GS1 DataBar Stacked, -GS1 DataBar Stacked Omnidirectional, -MicroPDF417, -PDF417.
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Standard interfaces	USB, RS-232
Input voltage	4.5 - 14 V
Power consumption	400 mA
Dimensions (WxDxH)	84 x 71 x 94 mm
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	198.5 g
