Datalogic MAGELLAN 8100 User Manual

2-16 Magellan
®
8100/8100Ω and 8200/8200Ω Scanner
Figure 2-9. Models 8103, 8203, 8104 and 8204 Long Scanner or Scanner/
Scale Cutout Dimensions
20.125"
(51.12cm)
0.75"
(1.905cm)
18.625"
(47.308cm)
Models 8103/8203
& Models 8104/8204
Dimensions
Models 8103/8203
& Models 8104/8204
Cutout
Models 8103/8203
& Models 8104/8204
Routed Supports
Rails
11.625"
(29.53cm)
0.75"
(1.905cm)
Max. Radius = 0.25"
(0.635cm) 4x
20.0 lb.
(9.07kg)
Scanner/Scale
Weight
15.2 lb.
(6.89kg)
Scanner
Weight
4.125" ± .062
(10.5cm)
5.1"
(12.95cm)
Window
9.35"
(23.75cm)
5.3"
(13.46cm)
6.46"
(16.41cm)
1.0"
(2.54cm)
1.93" (4.9cm)
0.375" (0.953cm)
1.16" (2.95cm)
0.375" (0.953cm)
13.54"
(34.39cm)
12.60"
(32.0cm)
PLATTER
20.0"
(50.8cm)
9.1"
(23.1cm)
11.1"
(28.19cm)
PLATTER
11.5"
(29.21cm)
SCANNER/SCALE
20.125" ±0.06"
(51.2 ±0.15 cm)
18.625" ±0.125"
(47.3 ±0.32 cm)
0.75"
(1.9 cm)
1.5"
(3.8 cm)
0.75"±0.125"
(1.9 ±0.32 cm)
0.75"±0.125"
(1.9 ±0.32 cm)
4.0"
(10.2 cm)
0.375" ± 0.03" (.95 ±.08 cm)
Liquid
Drainage
Liquid
Drainage
