xii
Matrix 210N™
Fixed Focus Models
Figure A
1
6
3
4
5
2
7
11
10
8
Device Labels
1
Mounting Holes (4)
2
Ethernet Connection LED
3
Ethernet Connector
4
Lens
9
Internal Illuminator
10
Good Read LED Spot (green)
11
Power - Serial - I/O Cable Connector
5
Power On LED
6
HMI X-PRESS Interface
7
Aiming System (Blue Ring)
8
9
