MATRIX 210N™ REFERENCE MANUAL
2.5 MODEL DESCRIPTION
Matrix 210N readers are described by their model number which indicates the characteristics
listed in the diagram below. Not all combinations are available. For a complete list of
combinations see the Models tab on the Product page of the website.
Illuminators
1 = Standard Internal Illuminator
2 = DPM Internal Illuminator with Diffuser
3 = DPM Internal Illuminator
Focus Distance
1 = Fixed Focus Near
2 = Fixed Focus Medium
3 = Fixed Focus Far
5 = Software Adjustable Focus (Liquid Lens)
Sensor Size
2 = WVGA (752x480)
Reading Window
0 = 90°
1 = Straight
Interface
0 = Serial
1 = Ethernet
2 = USB
Options
0 = Standard
1 = ESD Safe
2 = ESD Safe + YAG Cut Filters
