MATRIX 210N™ REFERENCE MANUAL
7.5.1 Backup
To perform a Backup:
1. From the DL.CODE Device menu, select either Single Reader Backup (to file on PC); or
Backup to external storage device.
NOTE: For ID-NET network Backup (Master only), select the Backup
current Internal Network configurations selection.
You will be reminded that configuration in temporary memory will not be saved so you should
save the configuration to the reader before performing Backup.
If you are performing a backup to a file you will be asked whether to include the firmware
or not.
At the end of the backup, DL.CODE shows a message indicating successful completion.
