MATRIX 210N™ REFERENCE MANUAL
5.7 USB CONNECTION
Matrix 210N USB models can be connected in a Point-to-Point layout to a local host through
their USB cable. No external power supply is necessary.
Figure 73 – Matrix 210N USB Point-to-Point Layout
One or more Matrix 210N USB models can be connected to a USB Hub. The HUB must be
able to supply 500 mA to each port.
Figure 74 – Matrix 210N USB Layout to HUB
