MATRIX 210N™ REFERENCE MANUAL
To view the connected Slave configurations:
1. Click on the Internal Network View tab at the bottom of the screen
2. Open the Master branch by clicking on the arrow to the left of the Master icon.
3. Select any slave.
4. Click The Configuration tab at the bottom of the screen.
By selecting the various configuration steps above you can visualize the slave configuration.
NOTE: You can modify some Slave Synchronized parameters from this view
but you cannot save them here.
To save changed slave parameters here, you must click on the Master and
Save the configuration overwriting it, making sure to save without Clone
Master Configuration on Slaves, otherwise all the Slave configuration
parameters will be overwritten.
