SOFTWARE CONFIGURATION
7. View Menu (Master Only):
1. [Exit] (returns to Main menu)
2. Standard (displays the Standard Reading Results screen during run mode)
3. Reading Mask (displays the Reading Mask or Reading Mask/Device State screen
during run mode) depends on the selection in DL.CODE see par. 7.9.1.
4. Network State (displays the Network State screen during run mode)
8. Extended Menu:
1. [Exit] (returns to Main menu)
2. Backup (performs Backup - uninterruptible)
3. Restore (performs Restore - uninterruptible)
4. Erase (erases the backup configuration in external memory - uninterruptible)
To move through the list press and release the Up or Down key.
To select an item or enter a submenu, press and release the Enter key. After executing an
HMI function the display shows a result message and then automatically exits from the menu
structure.
To exit a menu manually, press and release the Enter key at the [Exit] item or press the Up
and Down buttons simultaneously.
To exit from a running HMI function, press the Up and Down buttons simultaneously. These
functions will also exit upon their configured timeout.
NOTE: When the HMI Interface is entered from either the Local Device
(reader) or Remote Device (BM150), the key(s) on the other device are
disabled.
NOTE: When the reader is connected to DL.CODE, access to the BM150 HMI
Interface is disabled.
NOTE: The "Reset Reader to Factory Default Environment" function of the
HMI Interface is only available on the local device (reader), and not on the
BM150.
