Diagnostic Alarms:
Diagnostic error messages are sent to the BM150 display as numeric Alarm Codes, (even if
Failure Messages are selected for data transmission the numeric Alarm Code is sent to the
display).
A
l
e
r
t
:
F
a
i
l
u
r
e
#
X
X
X
R
R
R
N
N
N
X = numeric Alarm Code (see below for the list of Alarm Codes)
R = Device Network Type – MUL=Multidata, SYN=Synchronized, ALN=Alone
N = Device Network Setting – M00=ID-NET Network Master, Sxx= ID-NET Network Slave
address, Null string= Alone (no network)
Alarm
Code
Description
1
Slave No Reply
64
Slave Address Duplication
171
Protocol Index Failure
185
Backup Memory Communication Failure
187
Wrong Rotary Switch Selection
189
Fieldbus Communication Failure
191
Fieldbus Type Mismatch
193
Fieldbus Configuration Error
195
Fieldbus DHCP Problem
201
No XRF Slave(s) Detected
Slave Node Alarms (Master only):
A
l
e
r
t
:
I
D
-
N
E
T
N
o
d
e
#
X
X
M
i
s
s
i
n
g
R
R
R
M
0
0
X = slave node number (1-31)
R = Device Network Type – MUL=Multidata, SYN=Synchronized
Network State (Master only):
0
N
e
t
w
o
r
k
1
5
M
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
1
6
N
e
t
w
o
r
k
3
1
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
M = Master diagnostic condition; S = Slave diagnostic condition:
* = scanner OK
- =scanner not detected at startup
? =scanner detected at startup but not responding to diagnostic polling
! = scanner diagnostic error
