MATRIX 210N™ REFERENCE MANUAL
78
5
When using a Local Area Network (LAN), one or more Matrix 210N readers can be
connected to the network by using CAB-ETH-M0x cables:
Figure 63 - Ethernet Network Layout
CBX
Matrix 210N
Host
Switch
Power
CAB-ETH-M0x
CAB-DSxx-S
1
2
3
 Ethernet Interface
 Auxiliary Serial Interface (RS232 - Data Monitor)
 External Trigger (for One Shot or Phase Mode)
Alone
Alone
Alone
