Datalogic PowerScan PD9530 User Manual

it is possible to select a fixed channel with a frequency different
from the default; please contact Datalogic Technical Support for
information about this feature.
For the 910 models, the radio range
can change depending on the
Frequency Agility parameter value; in particular, at low speed, the
radio range is shorter when a fixed channel is programmed. See
the Radio Range values in
"Radio Features" on page 316 of
Technical Specifications.
Enter/Exit Programming Mode
Product Reference Guide 239
The frequency agility features are not equally supported for all model
speeds. Please refer to the following table:
Table 26. Frequency Agility
Mode Frequency hopping
Fixed Channel different
from d
efault
433 MHz Model
Compatibile No No
Normal, low speed Yes Yes
Normal, intermediate speed No No
Normal, high speed No No
910 MHz Model
Normal, low speed Yes Yes
Normal, high speed Yes Yes

Datalogic PowerScan PD9530 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Linear (1D) barcodes supported	-
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Product color	Black, Yellow
International Protection (IP) code	IP65
Input voltage	5 V
Power consumption	350 mA
Power source type	DC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Cables included	No

Weight and Dimensions

Depth	110 mm
Width	74 mm
Height	212 mm
Weight	330 g
