288 PowerScan™ PD9530/PBT9500/PM9500
Label ID
A Label ID is a customizable code of up to three ASCII characters (each can
be one of hex 0x01-0xFF), used to identify a bar code (symbology) type. It
can be appended previous to or following the transmitted bar code data
depending upon how this option is enabled. This feature provides options
for configuring custom Label IDs as a pre-loaded set (see "Label ID: Pre-
loaded Sets" below) or individually per symbology (see "Label ID: Set Individ-
ually Per Symbology" on
pa
ge 291). If you wish to program the reader to
always include an industry standard label identifier for ALL symbology types,
see "G
lobal AIM ID" on page 51.
Label ID: Pre-loaded Sets
The reader supports two pre-loaded sets of Label IDs. Table 38 shows the
USA and the EU sets.
CAUTION
When changing from one Label ID set to another, all other reader con-
figuration settings, including the host interface type, will be erased
and se
t to the standard factory defaults. Any custom configuration or
custom defaults will be lost.
Table 38 . Label ID Pre-loaded Sets
Symbology
USA Label ID set EU Label ID set
Default
Character
Default
ASCII
Default
Character
Default
ASCII
ABC CODABAR
S 530000 S 530000
ANKER PLESSEY
o 6F0000 o 6F0000
AZTEC
Az 417A00 ! 210000
CHINA SENSIBLE CODE
$S 245300 $S 245300
CODABAR
% 250000 R 520000
CODE11
CE 434500 b 620000
CODE128
# 230000 T 540000
CODE32
A 410000 X 580000
CODE39
* 2A0000 V 560000
CODE39 CIP
Y 590000 Y 590000
CODE39 DANISH PPT
$Y 245900 $Y 245900
CODE39 LAPOSTE
$a 246100 $a 246100
CODE39 PZN
$Z 245A00 $Z 245A00
CODE93
& 260000 U 550000
DATABAR 14
R4 523400 u 750000
DATABAR 14 COMPOSITE
R4 523400 c 523400
DATABAR EXPANDED
RX 525800 t 740000

Datalogic PowerScan PD9530 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Linear (1D) barcodes supported	-
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Product color	Black, Yellow
International Protection (IP) code	IP65
Input voltage	5 V
Power consumption	350 mA
Power source type	DC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Cables included	No

Weight and Dimensions

Depth	110 mm
Width	74 mm
Height	212 mm
Weight	330 g
