vPad-A1 OPERATORS MANUAL
TACHYCARDIA
• Atrial Tachycardia
• Paroxysmal Atrial Tachycardia
• 90 BPM Supraventricular Rhythm
• 120 BPM Supraventricular Rhythm
• 140 BPM Supraventricular Tachycardia
• 150 BPM Supraventricular Tachycardia
• 160 BPM Supraventricular Tachycardia
• 170 BPM Supraventricular Tachycardia
• 180 BPM Supraventricular Tachycardia
• 190 BPM Supraventricular Tachycardia
• 200 BPM Supraventricular Tachycardia
• 210 BPM Supraventricular Tachycardia
• 220 BPM Supraventricular Tachycardia
• 160 BPM Normal Sinus Rhythm
GENERAL 2
• Atrial Flutter
• Sinus Arrhythmia
• Miss 1 Beat, 80 BPM
• Miss Every 10
th
Beat, 80 BPM
• Miss Every 10
th
Beat, 120 BPM
• Nodal Rhythm
• Sinus Bradycardia, <60 BPM
ECG Performance Tests:
• Square Waves: 0.125 Hz, 2 Hz, 2.5 Hz
• Triangle Wave: 0.125 Hz, 2 Hz, 2.5 Hz
• Pulse: 60 BPM or 30 BPM (60 msec)
• Sine Waves: 0.05, 0.5, 1, 2, 5, 10, 25, 30, 40, 50, 60, 100 Hz, and 150 Hz
• R-Wave Detector Test: 30, 60, 80, 120, 200, or 250 BPM haver-triangle wave with
selectable width 8, 12, 20, 40, 60, 80, 100, 120,
140, 160, 180 and 200 msec
• QRS Detection Test 30, 60, 80, 120, 200, or 250 BPM QRS wave with selectable
width 8, 12, 20, 40, 60, 80, 100, 120,
140, 160, 180 and 200 msec
Specifications/Chapter 1 # Page 5
