vPad-A1 OPERATORS MANUAL
The Test Result interface displays all active parameter settings for ECG so that users can view them
as reference to check the DUT’s performance. Refer to section 5.1.2.1 -
Creating Test Results
for
further details on working with the
Result interface.
Assigning a “PASS” or “FAIL” will dismiss the current
Result interface and summon the next
Result in the Group. Users can also record a “SKIP” for this instance by pressing .
Touch the button if at any time it becomes
necessary to abort the AutoSequence. This will stop any testing
in progress and display the “View Results” screen. The most
recently displayed Test Result entry will be marked as
“TERMINATED” and the review window will show only the
Results assigned up to the point of stoppage.
If the “View Results” screen is from concluding an
AutoSequence, the options to erase Result entries will not be
available until users exit and re-enter the “View Results”
window. Additional tests or simulations may be added manually
to the Results buffer unless the user elects to Clear All or to
create a Test Record.
Figure 127
Automation and Test Records/Chapter 5 # Page 83
