Description of fields within Sub-Register 0x2D:08 – OTP_STAT
Reserved. Bits marked ‘-’ are reserved.
7.2.46.5 Sub-Register 0x2D:0A – OTP_RDAT
Register file: 0x2D – OTP Memory Interface, sub-register 0x0A is a 32-bit register. The data value read from
an OTP location will appear here after invoking the OTP read function. For details of the OTP memory map
and the procedures to read OTP memory, please refer to section 6.3 – Using the on-chip OTP memory.
7.2.46.6 Sub-Register 0x2D:0E – OTP_SRDAT
OTP Special Register Read Data
Register file: 0x2D – OTP Memory Interface, sub-register 0x0E is a 32-bit register. The data value stored in
the OTP SR (0x400) location will appear here after power up. For details of the OTP memory map and the
procedures to read OTP memory, please refer to section 6.3 – Using the on-chip OTP memory.
7.2.46.7 Sub-Register 0x2D:12 – OTP_SF
Register file: 0x2D – OTP Memory Interface, sub-register 0x12 is an 8-bit special function register used to
select and load special receiver operational parameter sets. See 7.2.46.8 – Receiver operating parameter sets
for details. The OTP_SF register contains the following fields:
REG:2D:12 – OTP_SF – OTP Special Function
The fields of the OTP_SF register are described below:
