Deep Sea Electronics Plc DSE6120 MKII

Specification
057-236 ISSUE: 1 Page 14 of 94
2.8.2.1.2 0-10V INPUT CONFIGURATION
Number 1 configurable ratiometric input
Full Scale 0 V to 10 V
Resolution 1%
Accuracy +/-2% of full scale voltage (±0.2 V) excluding transducer error
Max Common Mode Voltage ±2 V
Display Range
0 % to 250 %, 0 °C to 250 °C (32 °F to 482 °F) or 0 bar to 17.2 bar
(0 PSI to 250 PSI) subject to limits of the sensor and sensor
configuration
2.8.2.1.3 4-20 MA INPUT CONFIGURATION
Number 1 configurable ratiometric input
Full Scale 0 mA to 20 mA
Resolution 1%
Accuracy +/-2% of full scale resistance (±0.4 mA) excluding transducer error
Max Common Mode Voltage ±2 V
Display Range
0 % to 250 %, 0 °C to 250 °C (32 °F to 482 °F) or 0 bar to 17.2 bar
(0 PSI to 250 PSI) subject to limits of the sensor and sensor
configuration
2.8.2.2 ANALOGUE INPUT B
Input Type
Flexible: Configured for Coolant Temperature in the DSE default
configuration.
Flexible Options: Not used, Digital Input, Flexible Analogue &
Coolant Temperature
Flexible Input Selection
Pressure Sensor
Percentage Sensor
Temperature Sensor
Measurement Type
Resistance measurement by measuring voltage across sensor with a
fixed current applied
Arrangement Differential resistance measurement input
Measurement Current 11 mA ±10 %
Full Scale
480 Ω
Over Range / Fail
540 Ω
Resolution
1 °C (2 °F)
Accuracy
+/-2 % of full scale resistance (±9.6 Ω) excluding transducer error
Max Common Mode Voltage ±2 V
Display Range
0 % to 250 %, 0 °C to 250 °C (32 °F to 482 °F) or 0 bar to 17.2 bar
(0 PSI to 250 PSI) subject to limits of the sensor and sensor
configuration
