7.1 FRONT PANEL CONFIGURATION EDTIOR
7.1.1 ACCESSING THE FRONT PANEL CONFIGURATION EDITOR
NOTE: More comprehensive module configuration is possible via PC configuration
software. For further details of module configuration, refer to DSE Publication: 057- 224
DSE6110 MKII & DSE6110 MKII Configuration Software Manual.
• Ensure the engine is at rest and the module by pressing the Stop/Reset Mode
button.
• Press the Stop/Reset Mode
and Tick
buttons together to enter the front panel
configuration editor.
7.1.2 ENTERING PIN
NOTE: The PIN is not set by DSE when the module leaves the factory. If the module has a
PIN code set, this has been affected by your engine supplier who should be contacted if you
require the code. If the code has been ‘lost’ or ‘forgotten’, the module must be returned to
the DSE factory to have the module’s code removed. A charge is made for this procedure.
NB - This procedure cannot be performed away from the DSE factory.
NOTE: The PIN is automatically reset when the editor is exited (manually or
automatically) to ensure security.
• If a module security PIN has been set, the PIN request is then shown.
• Press the Tick
button, the first ‘#’ changes to ‘0’. Press the Previous
-
& Next
+
buttons to
adjust it to the correct value.
• Press the Next
+
button when the first digit is correctly entered. The digit you have just entered
now shows as ‘#’ for security.
• Press the Scroll Down
button to move back to adjust one of the previous digits.
• After editing the final PIN digit, press the Tick
button. The PIN is then checked for validity. If
the number is not correct, the PIN must re-entered.
• If the PIN has been successfully entered (or the module PIN has not been enabled), the editor is
displayed.
