Deep Sea Electronics Plc DSE6120 MKII

Specification
Page 15 of 94 057-236 ISSUE: 1
2.8.2.3 ANALOGUE INPUT C
Input Type
Flexible: Configured for Fuel Level Sensor in the DSE default
configuration
Flexible Options: Not used, Digital Input, Flexible Analogue & Fuel
Level Sensor
Flexible Input Selection
Pressure Sensor
Percentage Sensor
Temperature Sensor
Measurement Type
Resistance measurement by measuring voltage across sensor with
a fixed current applied
Arrangement Differential resistance measurement input
Measurement Current 11 mA ±10 %
Full Scale
480 Ω
Over Range / Fail
540 Ω
Resolution 1 %
Accuracy
+/-2 % of full scale resistance (±9.6 Ω) excluding transducer error
Max Common Mode Voltage ±2 V
Display Range
0 % to 250 %, 0 °C to 250 °C (32 °F to 482 °F) or 0 bar to 17.2 bar
(0 PSI to 250 PSI) subject to limits of the sensor and sensor
configuration
2.8.2.4 ANALOGUE INPUT D
Input Type
Flexible: Configured for Flexible Sensor, Pressure Sensor in the
DSE default configuration.
Flexible Options: Not used, Digital Input, Flexible Analogue & Oil
Sensor
Flexible Input Selection
Pressure Sensor
Percentage Sensor
Temperature Sensor
Measurement Type
Resistance measurement by measuring voltage across sensor with a
fixed current applied
Arrangement Differential resistance measurement input
Measurement Current 11 mA ±10 %
Full Scale
240 Ω
Over Range / Fail
270 Ω
Resolution 1%
Accuracy
±2 % of full scale resistance (±4.8 Ω) excluding transducer error
Max Common Mode Voltage ±2 V
Display Range
0 % to 250 %, 0 °C to 250 °C (32 °F to 482 °F) or 0 bar to 17.2 bar
(0 PSI to 250 PSI) subject to limits of the sensor and sensor
configuration
