4.4.6 ALARMS
When an alarm is active, the Common Alarm LED, illuminates and a message appears on the
module’s display. If configured, the external audible alarm also sounds.
The external audible alarm is silenced by pressing the Alarm Reset / Lamp Test
button.
The LCD display jumps from the ‘Information page’ to display the Alarm Page
1/2 Alarms
Low Oil Pressure
Warning
The LCD displays multiple alarms such as “Coolant Temperature High”, “Emergency Stop” and “Low
Coolant Warning”. These automatically scroll in the order that they occurred.
In the event of an alarm, the LCD displays the appropriate text. If an additional alarm then occurs,
the module displays the appropriate text.
Example:
1/2 Alarms
Low Oil Pressure
Warning
Coolant Temperature High
Shutdown
The type of alarm, e.g. Warning
The cause of alarm, e.g. Low Oil Pressure
Number of active alarms. This is
alarm 1 of a total of 2 active alarms
