Deep Sea Electronics Plc DSE6120 MKII

Specification
Page 21 of 94 057-236 ISSUE: 1
2.13 DIMENSIONS AND MOUNTING
2.13.1 DIMENSIONS
216 mm x 158 mm x 43 mm
(8.5” x 6.2” x 1.7”)
2.13.2 PANEL CUTOUT
184 mm x 137 mm
(7.2” x 5.3”)
2.13.3 WEIGHT
0.45 kg
(1.00 lb)
218 mm (8. 5 “) 43 mm (1.7 “)
33 mm (1.3 “)
158 mm (6.2 “)
