Description Of Controls
Page 51 of 94 057-236 ISSUE: 1
4.4.5 EXPANSION
NOTE: Depending upon the module’s configuration, some display screens may be
disabled. For further details of module configuration, refer to DSE Publication: 057-224
DSE6110 MKII & DSE6120 MKII Configuration Software Manual.
When input expansion modules are configured, these pages contain measured values derived from
the expansion analogue inputs.
Oil Temperature
80 °C
• DSE2130 ID0 Analogue Input E
• DSE2130 ID0 Analogue Input F
• DSE2130 ID0 Analogue Input G
• DSE2130 ID0 Analogue Input H
• DSE2130 ID1 Analogue Input E
• DSE2130 ID1 Analogue Input F
• DSE2130 ID1 Analogue Input G
• DSE2130 ID1 Analogue Input H
To Next Page
