5.2 STOP/RESET MODE
NOTE: If a digital input configured to Panel Lock is active, changing module modes is
not possible. Viewing the instruments and event logs is NOT affected by Panel Lock.
NOTE: For further details of module configuration, refer to DSE Publication: 057-224
DSE6110 MKII & DSE6120 MKII Configuration Software Manual.
Stop/Reset Mode is activated by pressing the Stop/Reset Mode
button.
In Stop/Reset Mode
, the module removes the generator from load (if necessary) before stopping
the engine if it is already running.
If the engine does not stop when requested, the Fail To Stop alarm is activated (subject to the setting
of the Fail to Stop timer). To detect the engine at rest the following must occur :
• Engine speed is zero as detected by the CAN ECU
• Generator AC Voltage and Frequency must be zero.
• Engine Charge Alternator Voltage must be zero.
• Oil pressure sensor must indicate low oil pressure
When the engine has stopped, it is possible to send configuration files to the module from DSE
Configuration Suite PC software and to enter the Front Panel Editor to change parameters.
Any latched alarms that have been cleared are reset when Stop/Reset Mode
is entered.
The engine is not started when in Stop/Reset Mode
. If remote start signals are given, the input is
ignored until Auto Mode
is entered.
When left in Stop/Reset Mode
with no presses of the fascia buttons and configured for Power
Save Mode, the module enters Power Save Mode. To ‘wake’ the module, press any fascia control
buttons.
Power Save Mode in the
DSE Configuration Suite
Software
