2 SPECIFICATION
2.1 SHORT NAMES
Short Name Description
DSE6000,DSE6xxx MKII All modules in the DSE6000 MKII range.
DSE6100,DSE61xx MKII All modules in the DSE61xx MKII range.
DSE6110 MKII DSE6110 MKII module/controller
DSE6120 MKII DSE6120 MKII module/controller
2.2 OPERATING TEMPERATURE
Module Description
DSE61xx MKII -30 ºC +70 ºC (-22 ºF +158 ºF )
Display Heater Variants -40 ºC +70 ºC (-40 ºF +158 ºF )
2.2.1 SCREEN HEATER OPERATION
Screen Heater Function Description
Turn On When Temperature Falls Below -10 ºC (+14 ºF)
Turn Off When Temperature Rises
Above
-5 ºC (+23 ºF)
2.3 REQUIREMENTS FOR UL CERTIFICATION
Screw Terminal
Tightening
Torque
4.5 lb-in (0.5 Nm)
Conductors
• Terminals suitable for connection of conductor size 12 AWG to 26 AWG
(0.5 mm² to 2.0 mm²).
• Conductor protection must be provided in accordance with NFPA 70, Article
240
• Low voltage circuits (35 volts or less) must be supplied from the engine
starting battery or an isolated secondary circuit.
• The communication, sensor, and/or battery derived circuit conductors shall be
separated and secured to maintain at least ¼” (6mm) separation from the
generator and mains connected circuit conductors unless all conductors are
rated 600 Volts or greater.
Current Inputs
Must be connected through UL Listed or Recognized isolating current
transformers with the secondary rating of 5A max.
Communication
Circuits
Must be connected to communication circuits of UL Listed equipment
Output Pilot Duty 0.5 A
Mounting
• Suitable for use in type 1 Enclosure Type rating with surrounding air
temperature -22 ºF to +158 ºF (-30 ºC to +70 ºC)
• Suitable for pollution degree 3 environments when voltage sensing inputs do
not exceed 300V. When used to monitor voltages over 300V device to be
install in an unventilated or filtered ventilation enclosure to maintain a pollution
degree 2 environment.
Operating
Temperature
-22 ºF to +158 ºF (-30 ºC to +70 ºC)
Storage
Temperature
-40 ºF to +176 ºF (-40 ºC to +80 ºC)
