Fault Description
Expansion Unit Failure
The module detects the DSE Net link to the expansion module has
failed or communications to the expansion module has been lost.
Generator kW Overload
The
measured
kW has risen above the
configured trip level for a
configured duration.
Generator Over Frequency
The generator output frequency has risen above the trip alarm
setting.
Generator Over Voltage
The generator output voltage has risen above the trip alarm
setting.
Generator Under Frequency
The generator output frequency has fallen below the trip alarm
setting after the Safety On timer has expired.
Generator Under Voltage
The generator output voltage has fallen below the pre-set alarm
setting after the Safety On timer has expired.
High Coolant Temperature
The module detects that the engine coolant temperature has
exceeded the high engine temperature trip alarm setting level after
the Safety On timer has expired.
High Fuel Level
The level detected by the fuel level sensor is above the high fuel
level trip alarm setting.
Low Fuel Level
The level detected by the fuel level sensor is below the low fuel
level trip alarm setting.
Low Oil Pressure
The module detects that the engine oil pressure has fallen below
the low oil pressure trip alarm setting level after the Safety On
timer has expired.
Loss Of Speed Sensing Signal
There is no speed signal received from the magnetic pickup
connected to the controller. Check distance and position of
magnetic pickup in relation to engine flywheel.
Maintenance Alarm 1
The module detects that the Maintenance Alarm 1 is due creating
a fault condition, the appropriate LCD message is displayed.
Maintenance Alarm 2
The module detects that the Maintenance Alarm 2 is due creating
a fault condition, the appropriate LCD message is displayed.
Maintenance Alarm 3
The module detects that the Maintenance Alarm 3 is due creating
a fault condition, the appropriate LCD message is displayed.
Oil Pressure Sensor Fault.
The module detects that the circuit to the oil pressure sensor has
been broken.
Over Speed
The engine speed has risen above the over speed trip alarm
setting
Under Speed
The engine speed has fallen below the under speed trip alarm
setting
2130 ID0 Analogue Input E to H
The module detects that an analogue input that has been user
configured to create a fault condition has become active on the
DSE2130 expansion module with ID0.
2130 ID0 Digital Input A to H
The module detects that a digital input that has been user
configured to create a fault condition has become active on the
DSE2130 expansion module with ID0.
2130 ID1 Analogue Input E to H
The module detects that an analogue input that has been user
configured to create a fault condition has become active on the
DSE2130 expansion module with ID1.
2130 ID1 Digital Input A to H
The module detects that a digital input that has been user
configured to create a fault condition has become active on the
DSE2130 expansion module with ID1.
