2770 EIC control
2774 EIC Speed Ramp
3000-3050 Digital input term. 10 to 15, without wire break
No. Setting Min. setting Max. setting Third
setting
Factory
setting
30X1 Dig. input no. XX Timer 0.0 s 3200.0 s - 10.0 s
30X2 Dig. input no. XX Relay output A R0 (none) R26 (relay 26) - R0 (none)
30X3 Dig. input no. XX Relay output B R0 (none) R26 (relay 26) - R0 (none)
30X4 Dig. input no. XX Enable OFF ON Inhibit OFF
30X5 Dig. input no. XX Fail class See description of fail classes
30X6 Dig. input no. XX NO/NC NO NC - NO
3490 Emergency stop (terminal 19 to 20)
No. Setting Min. setting Max. setting Factory
setting
3491 Emergency STOP Timer 0.0 s 60.0 s 0.2 s
3492 Emergency STOP Relay output A R0 (none) R26 (relay 26) R0 (none)
3493 Emergency STOP Relay output B R0 (none) R26 (relay 26) R0 (none)
3494 Emergency STOP Enable OFF ON ON
3495 Emergency STOP Fail class See description of fail classes
No. Setting Min. setting Max. setting Factory
setting
2771 EIC control Droop 0.0 % 25.0 % 0.0 %
2772 EIC control Scania rpm User
1500 rpm
1800 rpm
Low idle
User
2773 EIC control Cummins gain 0.00 10.00 5.00
No. Setting Min. setting Max. setting Factory
setting
2775 EIC Speed Ramp Set point 0.0RPM 120.0RPM 120.0RPM
2776 EIC Speed Ramp Timer 1.0 s 100.0 s 10.0 s
2777 EIC Speed Ramp Enable ON OFF OFF
