Deif GC-1F Installation Instructions

GC-1F Installation Instructions and Reference Handbook
DEIF A/S Page 93 of 123
Engine alarm settings (protection)
1000 Reverse power
No. Setting Min.
setting
Max. setting Third
setting
Factory
setting
1001 Reverse power Set point -50.0 % 0.0 % - -5.0 %
1002 Reverse power Timer 0.1 s 100.0 s - 10.0 s
1003 Reverse power Relay output A R0 (none) R26 (relay 26) - R0 none)
1004 Reverse power Relay output B R0 (none) R26 (relay 26) - R0 none)
1005 Reverse power Enable OFF ON Inhibit ON
1006 Reverse power Fail class Warning Shutdown - Trip
1030 Gen Over-current 1
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1031 Over-current 1 (P2) Set point 50.0 % 200.0 % - 115.0 %
1032 Over-current 1 (P2) Timer 0.1 s 3200.0 s - 10.0 s
1033 Over-current 1 Relay output A R0 (none) R26 (relay 26) - R0 (none)
1034 Over-current 1 Relay output B R0 (none) R26 (relay 26) - R0 (none)
1035 Over-current 1 Enable OFF ON Inhibit ON
1036 Over-current 1 Fail class Warning Shutdown - Trip
1040 Gen Over-current 2
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1041 Over-current 2 (P2) Set point 50.0 % 200.0 % - 120.0 %
1042 Over-current 2 (P2) Timer 0.1 s 3200.0 s - 5.0 s
1043 Over-current 2 Relay output A R0 (none) R26 (relay 26) - R0 (none)
1044 Over-current 2 Relay output B R0 (none) R26 (relay 26) - R0 (none)
1045 Over-current 2 Enable OFF ON Inhibit ON
1046 Over-current 2 Fail class Warning Shutdown - Trip
1130 Gen Short circuit 1
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1131 Over-current 2 (P2) Set point 150.0 % 350.0 % - 150.0 %
1132 Over-current 2 (P2) Timer 0 s 100.0 s - 2.0 s
1133 Over-current 2 Relay output A R0 (none) R26 (relay 26) - R0 (none)
1134 Over-current 2 Relay output B R0 (none) R26 (relay 26) - R0 (none)
1135 Over-current 2 Enable OFF ON Inhibit ON
1136 Over-current 2 Fail class Warning Shutdown - Warning
1140 Gen Short circuit 2
No. Setting Min. setting Max. setting Third
setting
Factory
setting
1141 Over-current 2 (P2) Set point 150.0 % 350.0 % - 150.0 %
1142 Over-current 2 (P2) Timer 0 s 100.0 s - 2.0 s
1143 Over-current 2 Relay output A R0 (none) R26 (relay 26) - R0 (none)
1144 Over-current 2 Relay output B R0 (none) R26 (relay 26) - R0 (none)
1145 Over-current 2 Enable OFF ON Inhibit ON
1146 Over-current 2 Fail class Warning Shutdown - Trip GB
Menu 1130 + 1140 is only available if GC-1F hardware is 1.05 and software 2.0x.x
