GC-1F Installation Instructions and Reference Handbook
DEIF A/S Page 104 of 123
4460 VDO water temp. input 3.1
No. Setting Min. setting Max. setting Factory
setting
4461 VDO 3.1 Set point 0 °C 150 °C 95 °C
4462 VDO 3.1 Delay 0.0 s 100.0 s 5.0 s
4463 VDO 3.1 Output A R0 (none) R26 (relay 26) R0 (none)
4464 VDO 3.1 Output B R0 (none) R26 (relay 26) R0 (none)
4465 VDO 3.1 Enable OFF ON OFF
4466 VDO 3.1 Fail class See description of fail classes
4470 VDO water temp. input 3.2
No. Setting Min. setting Max. setting Factory
setting
4471 VDO 3.2 Set point 0 °C 150 °C 95 °C
4472 VDO 3.2 Delay 0.0 s 100.0 s 5.0 s
4473 VDO 3.2 Output A R0 (none) R26 (relay 26) R0 (none)
4474 VDO 3.2 Output B R0 (none) R26 (relay 26) R0 (none)
4475 VDO 3.2 Enable OFF ON OFF
4476 VDO 3.2 Fail class See description of fail classes
4630 VDO low coolant temp. input 3.3
No. Setting Min. setting Max. setting Factory
setting
4631 VDO 3.3 Set point -50 °C 410 °C 10 °C
4632 VDO 3.3 Delay 0.0 s 10.0 s 1.0 s
4633 VDO 3.3 Output A R0 (none) R26 (relay 26) R0 (none)
4634 VDO 3.3 Output B R0 (none) R26 (relay 26) R0 (none)
4635 VDO 3.3 Enable OFF ON OFF
4636 VDO 3.3 Fail class See description of fail classes
RPM input
4510 Overspeed 1 (RPM input)
No. Setting Min. setting Max. setting Factory
setting
4511 Overspeed 1 Set point 0 % 400 % 110 %
4512 Overspeed 1 Timer 0.2 s 100.0 s 15.0 s
4513 Overspeed 1 Relay output A R0 (none) R26 (relay 26) R0 (none)
4514 Overspeed 1 Relay output B R0 (none) R26 (relay 26) R0 (none)
4515 Overspeed 1 Enable OFF ON OFF
4516 Overspeed 1 Fail class See description of fail classes
4520 Overspeed 2 (RPM input)
No. Setting Min. setting Max. setting Factory
setting
4521 Overspeed 2 Set point 0 % 400 % 110 %
4522 Overspeed 2 Timer 0.2 s 100.0 s 15.0 s
4523 Overspeed 2 Relay output A R0 (none) R26 (relay 26) R0 (none)
4524 Overspeed 2 Relay output B R0 (none) R26 (relay 26) R0 (none)
4525 Overspeed 2 Enable OFF ON OFF
4526 Overspeed 2 Fail class See description of fail classes
VDO type: See functional description.
Overspeed 1 and 2 are always active if enabled regardless of nominal setting.
Thus it is
p
ossible to set two levels of overs
p
eed.
