Deif GC-1F Installation Instructions

GC-1F Installation Instructions and Reference Handbook
DEIF A/S Page 122 of 123
External I/O setup
Analogue inputs
12000 Ext. an. in. 1.1
No. Setting Min. setting Max. setting Factory
setting
12000 Ext. an. in. 1.1 Set point -20000 20000 10
Delay 2.0 s 3200.0 s 10.0 s
Fail class See description of fail classes Warning
Relay output A Not used Option-
dependent
Not used
Relay output B Not used Not used
Enable OFF ON OFF
12010 Ext. an. in. 1.2
No. Setting Min. setting Max. setting Factory
setting
12010 Ext. an. in. 1.2 Set point -20000 20000 10
Delay 2.0 s 3200.0 s 10.0 s
Fail class See description of fail classes Warning
Relay output A Not used Option-
dependent
Not used
Relay output B Not used Not used
Enable OFF ON OFF
Analogue outputs
Digital inputs
12540 Ext. dig. in 1
No. Setting Min. setting Max. setting Factory
setting
12540 Ext. dig. in 1 Delay 2.0 s 3200.0 s 10.0 s
Fail class See description of fail classes Warning
Relay output A Not used Option-
dependent
Not used
Relay output B Not used Not used
Enable OFF ON OFF
Same order for settings 12030 to 12230.
The GC-1F does not support analogue outputs.
Same order for settings 12560 to 12690.
