Deif GC-1F Installation Instructions

GC-1F Installation Instructions and Reference Handbook
DEIF A/S Page 103 of 123
4390 0-20 4-20 mA 3.2
No. Setting Min. setting Max. setting Factory
setting
4391 0(4)-20 mA 3.2 Set point 4 mA 20 mA 10 mA
4392 0(4)-20 mA 3.2 Delay 0.0 s 100.0 s 5.0 s
4393 0(4)-20 mA 3.2 Output A R0 (none) R26 (relay 26) R0 (none)
4394 0(4)-20 mA 3.2 Output B R0 (none) R26 (relay 26) R0 (none)
4395 0(4)-20 mA 3.2 Enable OFF ON OFF
4396 0(4)-20 mA 3.2 Fail class See description of fail classes
VDO inputs
4220 VDO fuel level input 1.1
No. Setting Min. setting Max. setting Factory
setting
4221 Fuel level 1.1 (P3) Set point 0 % 100 % 10 %
4222 Fuel level 1.1 (P3) Delay 0.0 s 100.0 s 5.0 s
4223 Fuel level 1.1 Output A R0 (none) R26 (relay 26) R0 (none)
4224 Fuel level 1.1 Output B R0 (none) R26 (relay 26) R0 (none)
4225 Fuel level 1.1 Enable OFF ON OFF
4226 Fuel level 1.1 Fail class See description of fail classes
4230 VDO fuel level input 1.2
No. Setting Min. setting Max. setting Factory
setting
4231 Fuel level 1.2 (P3) Set point 0 % 100 % 99 %
4232 Fuel level 1.2 (P3) Delay 0.0 s 100.0 s 5.0 s
4233 Fuel level 1.2 Output A R0 (none) R26 (relay 26) R0 (none)
4234 Fuel level 1.2 Output B R0 (none) R26 (relay 26) R0 (none)
4235 Fuel level 1.2 Enable OFF ON OFF
4236 Fuel level 1.2 Fail class See description of fail classes
4310 VDO oil press. input 2.1
No. Setting (D) Min. setting Max. setting Factory
setting
4311 VDO 2.1 Set point 0.0 bar 10.0 bar 4.0 bar
4312 VDO 2.1 Delay 0.0 s 100.0 s 5.0 s
4313 VDO 2.1 Output A R0 (none) R26 (relay 26) R0 (none)
4314 VDO 2.1 Output B R0 (none) R26 (relay 26) R0 (none)
4315 VDO 2.1 Enable OFF ON OFF
4316 VDO 2.1 Fail class See description of fail classes
4320 VDO oil press. input 2.2
No. Setting (D) Min. setting Max. setting Factory
setting
4321 VDO 2.2 Set point 0.0 bar 10.0 bar 4.0 bar
4322 VDO 2.2 Delay 0.0 s 100.0 s 5.0 s
4323 VDO 2.2 Output A R0 (none) R26 (relay 26) R0 (none)
4324 VDO 2.2 Output B R0 (none) R26 (relay 26) R0 (none)
4325 VDO 2.2 Enable OFF ON OFF
4326 VDO 2.2 Fail class See description of fail classes

Deif GC-1F Specifications

General

Brand	Deif
Model	GC-1F
Category	Controller
Language	English
