Binary inputs
All binary inputs are 12/24 V DC bi-directional optocoupler type. The typical wiring is illustrated
below:
12/24 V DC
The binary inputs use fixed signals. Only the mode shift input and the test input
(if the timer is used) use pulse signal.
