Deif GC-1F Installation Instructions

GC-1F Installation Instructions and Reference Handbook
DEIF A/S Page 111 of 123
Hz/V monitoring settings
6220 Hz/V OK
No. Setting Min. setting Max. setting Factory
setting
6221 Hz/V OK* Timer 1.0 s 99.0 s 5.0 s
6222 Hz/V OK* Voltage 1 % 70 % 10 %
6223 Hz/V OK* Frequency 1 Hz 20 Hz 5 Hz
6230 GB close delay
No. Setting Min. setting Max. setting Factory
setting
6231 GB close delay Timer 0.0 s 30.0 s 0.5 s
6233 GB pulse ON time
No. Setting Min. setting Max. setting Factory
setting
6234 GB pulse ON time Timer 0.1 s 10.0 s 0.5 s
6290 Idle mode
No. Setting Min. setting Max. setting Factory
setting
6291 Idle mode Enable OFF ON OFF
6292 Idle mode Timer 1.0 s 300.0 s 5.0 s
6293 Idle mode Active Man. Man./aut. Aut.
Idle mode can be controlled via a binary input. If this is selected, the idle mode remains as long
as the input is ON. If a binary input is not used, the idle mode can be selected to be active for
manual or auto or both running modes.
- Both manual and auto: Select Man./Auto
- Manual only: Select Man.
- Auto only: Select Auto
6320 Engine heater on
No. Setting Min. setting Max. setting Factory
setting
6321 External heater on Set point 0 C/F 100 C/F 10 C/F
6330 Engine heater off
No. Setting Min. setting Max. setting Factory
setting
6331 External heater off Set point 0 C/F 100 C/F 20 C/F
The setting ranges refer to nominal setting (nominal voltage +/- setting %, nominal
frequency +/- setting Hz).
In order to make the external heater function work, a relay must be designated
to this function in the output settings.
