GC-1F Installation Instructions and Reference Handbook
DEIF A/S Page 112 of 123
6350 D+ input
No. Setting Min. setting Max. setting Factory
setting
6351 D+ input (P3) Timer 0.0 s 100.0 s 10.0 s
6352 D+ input Relay output A R0 (none) R26 (relay 26) R0 (none)
6353 D+ input Enable OFF ON OFF
6354 D+ input NO/NC NO NC NO
6360 GB on water temp.
No. Setting Min. setting Max. setting Factory
setting
6361 GB on water temp. Set point 0 C/F 100 C/F 40 C/F
6362 GB on water temp. Enable OFF ON OFF
6550 Fuel pump logic
No. Setting Min. setting Max. setting Factory
setting
6551 Fuel pump logic (P3) Set point 1 0 % 100 % 20 %
6552 Fuel pump logic (P3) Set point 2 0 % 100 % 90 %
6553 Fuel pump logic (P3) Timer 0.1 s 300.0 s 60.0 s
6554 Fuel pump logic Enable OFF ON OFF
6560 Cool-down timeout
No. Setting Min. setting Max. setting Factory
setting
6561 Cool-down timeout Timer 0.0 s 9999.0 s 900.0 s
6562 Cool-down timeout Relay output A R0 (none) R26 (relay 26) R0 (none)
6563 Cool-down timeout Relay output B R0 (none) R26 (relay 26) R0 (none)
6570 Oil press. run detection
No. Setting Min. setting Max. setting Factory
setting
6571 Oil press. run detection Set point 0 bar/PSI 150 bar/PSI 1 bar/PSI
6572 Oil press. run detection Enable OFF ON OFF
If the D+ input is selected to be ON, this will be used as a running feedback. The
D+ output from the charge generator must be connected to the input terminal
configured to this function. The terminal 9 (common for terminals 10 to 15) must
be connected to +, otherwise the D+ input does not work.
Parameter 6570 Oil pres. run detection makes it possible to use the oil pressure
as a running feedback.
10980 Config. input 1 must be set to VDO to activate the fuel pump logic.
A relay must be configured to fuel pump in output settings.
