Deif GC-1F Installation Instructions

GC-1F Installation Instructions and Reference Handbook
DEIF A/S Page 113 of 123
6700 Diode compensation
No. Setting Min. setting Max. setting Factory
setting
6700 Diode compensation Set point 0 V 1 V 0 V
6940 Alarm LED function
No. Setting Min. setting Max. setting Factory
setting
6941 Alarm LED function Customer Red/red
(Warning/
shutdown)
Amber/red
(Warning/
shutdown)
Red/red
(Warning/
shutdown)
6950 Parameter group 1
No. Setting Min. setting Max. setting Factory
setting
6950 Parameter group 1 Enable OFF ON OFF
6960 Parameter group 2
No. Setting Min. setting Max. setting Factory
setting
6960 Parameter group 2 Enable OFF ON OFF
6970 Parameter group 3
No. Setting Min. setting Max. setting Factory
setting
6970 Parameter group 3 Enable OFF ON OFF
6980 Sleep mode
No. Setting Min. setting Max. setting Factory
setting
6981 Sleep Timer 0 sec. 1800 sec. 600 sec.
6982 Sleep ON/OFF OFF ON OFF
The sleep mode is a standstill power saving mode. If the engine is stopped and nothing has
happened within the time setting, the unit will enter sleep mode, that is the most power
consuming functions (for example display) are turned off. As soon as an event occurs (a button
is activated, the input state changes), the sleep mode is ended.
7040 AMF test function
No. Setting Min.
setting
Second
setting
Max.
setting
Factory
setting
7042 Activation Set point Digital input Button Digital input
or button
Button
7041 Timer Timer 0.0 s - 3200.0 s 30.0 s
7043 Enable Enable OFF - ON ON
If a parameter list is enabled, the parameters marked (PX) are available in the
display parameter list.
The parameter 6700 can add an offset to the supply voltage measurement
displayed. This can be useful, if a diode is mounted in the supply connection.
